MONITOR
• 13 × 10 2-line high visibility LCD
• 728-variable colour display & Illuminated keys
SUPORTED MEDIA
• CD-R/ RW ready
AUDIO FEATURES
• 3-Band Parametric EQ
• Built-in Low pass / high pass filters
• 2V / 4-channel audio pre-out
TUNER SECTION
• Frequency Bands : FM/AM
• FM: (MHz) 0.05 MHz steps : 87.5 - 108.0
• AM: (kHz) 9 kHz steps : 531 - 1629
USB SECTION
• USB Ports : 1 (Front)
• Supported File Format : MP3 / WMA
CD SECTION
• S/N Ratio (dB) 1 kHz : 100dB
• Frequency Response (Hz) : 20 - 20,000
• Dynamic Range (dB) 1 kHz : 80dB
• Harmonic Distortion (%) : 0.003%
• Supported File Format : CDDA / MP3 / WMA
iPod SECTION
• Direct iPod Control : Yes via USB
• iPhone Compatible : YES
• Simple Control ( Operation from iPod) : NO
• Video File Browsing and Control : NOA
AUDIO SECTION
• Power Output : 20W x 4 channel maximum power output
GENERAL
• Dimensions (W x H x D) (mm) : 178 x 100 x 155
• Weight (Kg) : 1.55
• Power Consumption : less than 15A
• Power Requirement : 14.4V DC (10.8~15.6V)
• Speaker Impedance : 4Ω (4Ω to 8Ω allowable)
