ITEM
DESCRIPTIONS


ORDER NUMBER
  LAPIS
1
1


Matte White -
With in-line mounting plate, arm and door side cover caps. Snap-on assembly




Full overlay - Integrated soft-closing 110° Opening
Full overlay - Push-to-open 94° Opening

  H-SO110FL.WH
H-PU094FL.WH

  Gloss Black
  Full overlay - Integrated soft-closing 110° Opening
Full overlay - Push-to-open 94° Opening
  H-SO110FL.BL
H-PU094FL.BL

  TITANIUM1
1
  110° opening angle snap-on assembly
Premium: with titanium in-line mounting plate safety caps and door
    Full overlay - integrated soft-closing
Half overlay - integrated soft-closing		   H-SO110FP.TI
H-SO110HP.Ti

  SILENTIA - Integrated soft closing hinges
1
1   110° opening angle snap-on assembly
Premium: with in-line mounting plate, safety cap & door cover cap
  Full overlay - premium in-line mounting plate, safety cap & door cover cap
Half overlay - premium in-line mounting plate, safety cap & door cover cap
Inset - premium in-line mounting plate, safety cap & door cover cap
   H-SO110FP
H-SO110HP
H-SO110IP
  110° opening angle snap-on assembly
Standard: with cruciform mounting plate and safety cap
  Full overlay - standard cruciform mounting plate and safety cap
Half overlay - standard cruciform mounting plate and safety cap
Inset - standard cruciform mounting plate and safety cap		   H-SO110FS
H-SO110HS
H-SO110IS
  155° opening angle snap-on assembly
Zero prostrusion feature

  Full overlay - premium in-line mounting plate
Full overlay - standard cruciform mounting plate		   H-SO155FP
H-SO155FS
  105° opening angle snap-on assembly
For narrow aluminum frames
  Full overlay - premium in-line mounting plate and safety cap
Full overlay - standard cruciform mounting plate and safety cap 		  H-SO105FP.AL
H-SO105FS.AL
  Silentia integrated soft-closing hinge accessories

  1.8mm spacer for Silentia 110° opening hinges - For wide aluminum frames
1.8mm spacer for Silentia 155° opening hinges - For wide aluminum frames		   S2XX86KT
S2XF86KT

  Push-to-open hinges with reverse-spring technology
1
1   110° opening angle snap-on assembly
Premium: with in-line mounting plate, safety cap and door cover cap
  Full overlay - premium in-line mounting plate, safety cap & door cover cap
Half overlay - premium in-line mounting plate, safety cap & door cover cap
Inset - premium in-line mounting plate, safety cap & door cover cap 		  H-PU110FP
H-PU110HP
H-PU110IP
  110° opening angle snap-on assembly
Standard: with cruciform mounting plate and safety cap
  Full overlay - standard cruciform mounting plate & safety cap
Half overlay - standard cruciform mounting plate & safety cap
Inset - standard cruciform mounting plate & safety cap		   H-PU110FS
H-PU110HS
H-PU110IS
  155° opening angle snap-on assembly
Zero prostrusion feature
  Full overlay - premium in-line mounting plate
Full overlay - standard cruciform mounting plate		   H-PU155FP
H-PU155FS
  105° opening angle snap-on assembly
For narrow aluminum frames
  Full overlay - premium in-line mounting plate and safety cap
Full overlay - standard cruciform mounting plate and safety cap
  H-PU105FP.AL
H-PU105FS.AL

    Push-to-open hinge accessories
  Regular magnetic push
  With regular catch plate for 1,000mm tall doors   H-PUREGMAG.REGPLATE
  Supplementary magnet
  With regular catch plate to increase magnetic hold
Has to be used with regular push		   H-PUSTRMAG.REGPLATE
  Adapter for magnetic push
  For half overlay and inset applications.
With depth adjustment.		   H-PUADPMAG
  Regular magnetic push
  With strong catch plate for 2,000mm tall doors   H-PUREGMAG.STRPLATE
  Supplementary magnet
  With strong catch plate to further
increase magnetic hold. Has to be used with regular push.		   H-PUSTRMAG.STRPLATE
  Mechanical push and catcher (for any height)
With depth and sideways adjustment.		   H-PUMECH

  BASIC - Self closing hinges
1
1   110° opening angle snap-on assembly
Premium: with in-line mounting plate, safety cap & door cover cap

  Full overlay - premium in-line mounting plate, safety cap & door cover cap
Half overlay - premium in-line mounting plate, safety cap & door cover cap
Inset - premium in-line mounting plate, safety cap & door cover cap		   H-BA110FP
H-BA110HP
H-BA110IP
  110° opening angle snap-on assembly
Standard: with cruciform mounting plate and safety cap
  Full overlay - standard cruciform mounting plate and safety cap
Half overlay - standard cruciform mounting plate and safety cap
Inset - standard cruciform mounting plate and safety cap		   H-BA110FS
H-BA110HS
H-BA110IS
  110° opening angle slide-on assembly
Standard: with slide-on cruciform mounting plate
  Full overlay - standard slide-on cruciform mounting plate
Half overlay - standard slide-on cruciform mounting plate
Inset - standard slide-on cruciform mounting plate		   H-BA110FS.SLIDE
H-BA110HS.SLIDE
H-BA110IS.SLIDE
    Basic self-closing hinge accessories

  Smove adjustable strength soft-closing adapter
1 Smove can hold upto 1,500mm to 2,000mm tall doors
Only works with cruciform mounting plates
  Full overlay
Half overlay
Inset		   H-BASMOVEFS
H-BASMOVEHS
H-BASMOVEIS

  DRAWER RUNNERS - LINEABOX
1
1

 Aluminum Drawer Boxes
    Available Colors

      Standard Medium fronted 2-sided profiles (104mm height)
  Change XX to the color code
  Smove - soft-closing full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   SM30 - SO300FP.XX
SM30 - SO350FP.XX
SM30 - SO400FP.XX
SM30 - SO450FP.XX
SM30 - SO500FP.XX
    Push - push-to-open full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   SM30 - PU300FP.XX
SM30 - PU350FP.XX
SM30 - PU400FP.XX
SM30 - PU450FP.XX
SM30 - PU500FP.XX

      Standard High fronted 2-sided profiles (180mm height)
  Change XX to the color code
  Smove - soft-closing full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   SH30 - SO300FP.XX
SH30 - SO350FP.XX
SH30 - SO400FP.XX
SH30 - SO450FP.XX
SH30 - SO500FP.XX
    Push - push-to-open full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   SH30 - PU300FP.XX
SH30 - PU350FP.XX
SH30 - PU400FP.XX
SH30 - PU450FP.XX
SH30 - PU500FP.XX



Aluminum Sink Drawers
  Available Colors

      Under-sink Medium fronted 2-sided profiles (104mm height)
  Change XX to the color code
  Smove - soft-closing full-extension drawers
500mm (20 inches)		   UM30 - SO500FP.XX
  Push - push-to-open full-extension drawers
500mm (20 inches)		   UM30 - PU500FP.XX

      Under-sink High fronted 2-sided profiles (180mm height)
  Change XX to the color code
  Smove - soft-closing full-extension drawers
500mm (20 inches)		   UH30 - SO500FP.XX
  Push - push-to-open full-extension drawers
500mm (20 inches)		   UH30 - PU500FP.XX


Narrow Aluminum Drawer Boxes
  Available Colors

      Medium (104mm) + Medium (104mm) narrow drawers 2-sided profiles
  Change XX to the color code
  Smove - soft-closing full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   2M30 - SO300FP.XX
2M30 - SO350FP.XX
2M30 - SO400FP.XX
2M30 - SO450FP.XX
2M30 - SO500FP.XX

      Medium (104mm) + High (180mm) narrow drawers 2-sided profiles
  Change XX to the color code
  Smove - soft-closing full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   MH30 - SO300FP.XX
MH30 - SO350FP.XX
MH30 - SO400FP.XX
MH30 - SO450FP.XX
MH30 - SO500FP.XX

      High (180mm) + High (180mm) narrow drawers 2-sided profiles
  Change XX to the color code
  Smove - soft-closing full-extension drawers
300mm (12 inches) - requires cutting of profile
350mm (14 inches)
400mm (16 inches) - requires cutting of profile
450mm (18 inches) - requires cutting of profile
500mm (20 inches)		   2H30 - SO300FP.XX
2H30 - SO350FP.XX
2H30 - SO400FP.XX
2H30 - SO450FP.XX
2H30 - SO500FP.XX

  DRAWER RUNNERS - Futura Runners
1

  Futura full extension
undermount drawer runners
with standard adjustable clips		 Futura Smove
Full extension soft-closing		   Futura Push
Full extension push-to-open




 300mm (12 inches) runner length
350mm (14 inches) runner length
400mm (16 inches) runner length
450mm (18 inches) runner length
500mm (20 inches) runner length
550mm (22 inches) runner length 		R30-SO300FS
R30-SO350FS
R30-SO400FS
R30-SO450FS
R30-SO500FS
R30-SO550FS		   R30-PU300FS
R30-PU350FS
R30-PU400FS
R30-PU450FS
R30-PU500FS
R30-PU550FS

  Futura partial extension
undermount drawer runners
with standard adjustable clips





 350mm (14 inches) runner length
450mm (18 inches) runner length
500mm (20 inches) runner length 		R30-SO350PS
R30-SO450PS
R30-SO500PS

  DRAWER RUNNERS Unica Shelf - full extension undermount drawer runners
1
1   Unica: Push-to-open with integrated soft-closing.
Full extension undermount drawer runners w/ premium 3-way adjustable clips
  350mm (14 inches) runner length
500mm (20 inches) runner length 		  R30-UNIC350FP
R30-UNIC500FP

  Shelf Smove full extension soft-closing bottom panel-mounted shelf runners
with standard adjustable clips
  350mm (14 inches) runner length
450mm (18 inches) runner length
500mm (20 inches) runner length 		  R30-SO350FS.SHELF
R30-SO450FS.SHELF
R30-SO500FS.SHELF
  Optional support for rear hook for boards less than 16mm thick (pair)
   825650000

  LIFTING OPENING SYSTEMS - Flap Door
1
1

  Lift Opening Systems: Flap door with Smove soft-closing
Select the proper piston strength in the chart below and
replace the XXX in the catalogue number with the piston strength
  For 300mm to 400mm door height - Single arm
  600mm door width
900mm door width
1200mm door width
L-SOFLPS060X.XXX
L-SOFLPS090X.XXX
L-SOFLPS120X.XXX
L-PUFLPS060X.XXX
L-PUFLPS090X.XXX
L-PUFLPS120X.XXX
      Only 1 arm is needed up to 1200mm door width.
  Replace "X" in the catalogue number with "L" for left arm and "R" for right arm.
    For 500mm to 600mm door height
    600mm door width
900mm door width
1200mm door width
L-SOFLPL060X.XXX
L-SOFLPL090P.XXX
L-SOFLPL120P.XXX
L-PUFLPL060X.XXX
L-PUFLPL090P.XXX
L-PUFLPL120P.XXX
      Only 1 arm is needed up to 1200mm door width.
  Replace "X" in the catalogue number with "L" for left arm and "R" for right arm.
    Piston chart in newtons. Replace the XXX above with the correct piston strength



   MDF Boards
  Height\Width             600mm       900mm       1200mm
360mm to 400mm      150N           250N           350N
440mm to 600mm      350N           350N           450N
  MFC Boards
  Height\Width             600mm       900mm       1200mm
360mm to 400mm      150N           250N           350N
440mm to 600mm      350N           350N           350N

  LIFTING OPENING SYSTEMS - Folding Door
1
1

  Lift Opening Systems: Folding door with Smove soft-closing
Select the proper piston strength in the chart below and
replace the XXX in the catalogue number with the piston strength
  For 700mm to 750mm door height - Single arm
  600mm door width
L-SOFOL060X.XXX
      Only 1 arm is needed for 600mm door width.
 Replace "X" in the catalogue number with "L" for left arm and "R" for right arm.
    For 700mm to 750mm door height - Pair arms
  900mm door width
1200mm door width
L-SOFOL090P.XXX
L-SOFOL120P.XXX
    Piston chart in newtons. Replace the XXX above with the correct piston strength



   MDF Boards
  Height\Width             600mm       900mm       1200mm
700mm to 750mm      450N           400N           500N
  MFC Boards
  Height\Width             600mm       900mm       1200mm
700mm to 750mm      400N           300N          400N

  LIFTING OPENING SYSTEMS - Parallel Door
1
1

  Lift Opening Systems: Parallel door with Smove soft-closing
Select the proper piston strength in the chart below and
replace the XXX in the catalogue number with the piston strength
  For 360mm to 440mm door height - Small arm
  600mm door width
900mm door width
1200mm door width
L-SOPARS060.XXX
L-SOPARS090.XXX
L-SOPARS120.XXX
  For 440mm to 660mm door height - Large arm
  600mm door width
900mm door width
1200mm door width
L-SOPARL060.XXX
L-SOPARL090.XXX
L-SOPARL120.XXX


    Piston chart in newtons. Replace the XXX above with the correct piston strength



   Height\Width         600mm       900mm       1200mm


MDF Boards
  360mm to 440mm      100N            100N             150N
  440mm to 660mm      250N            350N             450N
    MFC Boards
    360mm to 440mm      100N            100N             100N
  440mm to 660mm      250N            350N             450N

  LIFTING OPENING SYSTEMS - Swing Door
1
1

  Lift Opening Systems: Swing door with Smove soft-closing
Select the proper piston strength in the chart below and
replace the XXX in the catalogue number with the piston strength
  For 360mm to 480mm door height
  600mm to 1200mm door width
L-SOSWINGS.XXX
  For 600mm to 720mm door height
  600mm to 1200mm door width
L-SOSWINGL.XXX


    Piston chart in newtons. Replace the XXX above with the correct piston strength
    Height\Width         600mm       900mm       1200mm



MDF Boards
  360mm to 440mm      100N            100N              100N
  440mm to 660mm      150N            250N              350N
    MFC Boards
    360mm to 440mm      100N            100N              100N
    440mm to 660mm      150N            150N              250N

  SLIDING DOOR SYSTEMS - Coplanar
1
1
  MEDIUM COPLANAR
Sliding Door Systems		 WITHOUT FRAME
for wooden doors		   WITH FRAME
for glass doors


Slider M50
50 kg coplanar sliding door systems

1800mm to 2000mm
2000mm to 2200mm
2400mm to 2600mm
3000mm to 3200mm

 S-M501820
S-M502022
S-M502426
S-M503032		   S-M501820.GL
S-M502022.GL
S-M502426.GL
S-M503032.GL

  Optional intermediate divider frame
3000mm profile		 S-DIVIDER3000

  SMALL COPLANAR
Sliding Door Systems
 FLOOR UNIT


SLIDER S20
20 kg coplanar sliding door systems

1800mm
2000mm
2400mm
3000mm

 S-S201800.FL
S-S202000.FL
S-S202400.FL
S-S203000.FL

  SMALL COPLANAR
Sliding Door Systems
 WALL UNIT


SLIDER S20
20 kg coplanar sliding door systems

1800mm
2000mm
2400mm
3000mm

 S-S201800.WA
S-S202000.WA
S-S202400.WA
S-S203000.WA

  SLIDING DOOR SYSTEMS - Glow+ Overlapping
1
1
  Overlapping sliding door systems
70 kg overlapping sliding door systems		 WITHOUT FRAME
for wooden doors		   WITH FRAME
for glass doors
  2 doors 3000mm profile
3 doors 3000mm profile
 S-GLOW2DOOR
S-GLOW3DOOR
   S-GLOW2DOOR.GL
S-GLOW3DOOR.GL

  Optional intermediate divider frame
  3000mm profile     S-DIVIDER3000

   POCKET DOOR SYSTEMS - Eclipse
1
1
  Eclipse 24kg pocket door systems   ORDER NUMBER
  Eclipse 24kg pocket door systems
Door width 500mm to 700mm
Door height 1900mm to 2200mm

  Right door
Left door
Pair doors		   S-ECLIPSE1922.RI
S-ECLIPSE1922.LE
S-ECLIPSE1922
